• In this quite unique turbine system, heavy stable torque is generated to rotate generator in whole range of 360 degree slowly as absorbing gravity acceleration by continuing supply light pressure as a trigger to control bias of water flux weight.
• All the movements are reacting smoothly relative every counter movement that is amplified by gravity leverage and it enables to generate incredible significant torque energy by extremely light trigger.
• Absorbing gravity acceleration perfectly means relative speed going up limitlessly and that means the energy is continued to be increased by the square of its velocity as well.
• The fundamental technical theory is too complicated to analyze with any mathematics or even hyper quantum computer because it must add much complex analog time axis on the calculating process which means different dimension. But contrary the physical structure is quite simple and very easy to scale up or scale out, and never happen to serious accident or fatal problem, and other much even better is that bigger scale makes even more simplifying the structure components.
• Increasing the diameter of the turbine core synergistically increases circumferential speed and torque, eliminating the need for an acceleration gear to rotate the generator, further increasing power generation efficiency.

• Trigger pump energy consumption: 1.5W/h (watt meter value / not supplied from system feedback / Power source: General AC100V 50Hz)
• Output Torque: 3.6 kg*cm (actual data)
• Rotational Speed: 0.8 rpm (actual data)
• Torque Energy: 0.03Ws : 105W/h (calculated from actual)
• Actual Generated Electricity: 2V * 5mA : 0.01Ws : 36W/h
• Mechanical friction loss of acceleration gear: over 60%

If the trigger power (1.5W/h) is to be Input Energy, The Output power energy is to be 105W/h at the actual Torque Energy Value, 36W/h at the actual Electrical Energy Value, either way the energy has been amplified by well over severral dozen times actually. But in the fact, the energy was not to be amplified but it is as the result that gravity wave motives increasing torque significantly by the chain reaction of that drive system.

The mysterious phenomenon that the pump’s energy consumption raise to 2.2W/h from 1.5W/h after taking connection tube off in spite of released from load of pumping up, the factor is that the pump was exposed much stronger pressure of atmospheric at that moment. And the energy for pumping up of water is spread to horizontal direction and forced to consume more energy to move more amount of water to follow direction of gravity instead of lifting of water. This phenomenon proofs that relative pressure balance can effect contrary for present three dimensional physical energy calculation.

The Simple Scale Out Model

• Trigger pump energy consumption: 6.6W/h (watt meter value / not supplied from system feedback / Power source: General AC100V 50Hz)
• Total Output Torque: 3.6 kg*cm * 3 cores : 108 kg*cm (actual data)
• Rotational Speed (all cores): 0.8 rpm (actual data)
• Total Torque Energy: 0.03Ws * 3 cores: 324W/h (calculated from actual)
• Actual Generated Electricity: 2V * 5mA * 3 cores : 108W/h

Although the extremely simple connection method increases the power consumption of the trigger energy, it generates an amazing torque energy from an extremely small amount of potential energy (a small amount of water falling from above at only 35cc/sec).

Just by looking at the operation of the video, it can be seen that an amazing amount of energy is being generated, and at the same time the incredible result has been proven on physical calculation.

Performance

Performance

Performance

Performance

For Anyone / Anywhere / Anytime

Huge & Clean Energy on demand

Not required followings

• Fuels / Artificial Energy Sources
• Restriction to place (even available on ocean / mountain / under basement / forest / jungle /desert)
• Special facility / big construction to install
• Operation labor / high skill to control
• Often maintenance (inside core is completely maintenance free)
• Natural disaster countermeasures

Expected “Price” of the product or “Cost” of the manufacturing

The Price or Cost is all depends on following factors;

• Business Model / Purpose of Use / Manufacturing Style / Quantity of production / Design of Final Product / Place of installing Environment / Materials of the Parts / Composing methods / etc
• In accordance with the business model, adequate considerations for Manufacture’s Margin / Product Dealer’s Margin / Service Dealer’s Margin / Service Model (Products Sals / Electricity Service / Lease Service) shall be required.
• Depending on the above factors, the product unit price and manufacturing unit price will be vary slightly depending on the assembly process design and production system. However, this technology’s physical principle is analogically quite complex, but the physical structure is quite simple and it does not depends fundamentally on complex Hi-Tech controlling system or expensive materials in manufacturing and operation process. And it will be discovered further more many of epochal factors (invention) to enable to decrease the cost in that product development, but unless special requirement or usage coming up no elements to increase cost.
• Anyway, if you confirm with your eyes by your self that this system actually works generating electricity from “gravity as power source”, you will know such those initial cost or manufacturing cost does not worth to talk about. And you will know what the most important matter is. It is “Time”. Because the time (gravitational acceleration) creates valuable clean and stable energy on demand from “zero calorie” and realize carbon neutral society at same time in this system.

As Vessel Engine

In the process of extracting huge torque energy, The Gravity Wave Engine is that creates a flow of water that sucks in a large amount of seawater from the front and discharges it to the rear, thereby creating a powerful ship’s propulsion force and at the same time being able to generate a large amount of power.

The larger the displacement of a ship, the higher the air pressure and water pressure will naturally be generated, and the more electricity can be generated.

Able to Create Clean Fuels

Hydrogen fuel is attracting attention as a next-generation fuel as it is carbon neutral and can generate explosive power energy equal to or greater than that of gasoline engines, but a huge amount of electricity is required to generate hydrogen fuel. As a result, there is no prospect of its widespread use. However, if the electricity is to be generated by the Gravity Wave Engine, that problem can be easily solved.
